Docker配置手册-基本操作与管理

3.1 创建带有ssh服务的Docker镜像

1) 开启一个新的容器,并在容器中安装ssh服务 [root@docker1 ~]# docker run --name snowchuai -h snow -it centos /bin/bash [root@snow /]# yum install openssh openssh-server passwd -y 或 [root@snow /]# docker run centos /bin/bash -c "yum -y update; yum install openssh openssh-server passwd -y" 2) 做好服务的相关配置 3) 在容器中为sshd生成ssh所需的主机密码 [root@snow ~]# ssh-keygen -t rsa -f /etc/ssh/ssh_host_rsa_key -q -N '' [root@snow ~]# ssh-keygen -t ecdsa -f /etc/ssh/ssh_host_ecdsa_key -q -N '' [root@snow ~]# ssh-keygen -t ed25519 -f /etc/ssh/ssh_host_ed25519_key -q -N '' 4) 修改容器的root密码 [root@snow ~]# passwd 5) 退出docker容器 [root@snow ~]# exit exit 6) 获取DockerID或Docker名 [root@docker1 ~]# dockerid=$(docker ps -a | awk '{print $1}' | sed 1d) && echo $dockerid 7) 生成Docker镜像 参数说明: -m “信息说明” [root@docker1 ~]# docker commit -m 'centos-ssh' $dockerid snowchuai/centos-sshd sha256:ae717ca509d99ac4adb9c821821c3b6cb9e8b89eaaa2d3f36ddc517d8f5fc17b [root@docker1 ~]# docker image list REPOSITORY TAG IMAGE ID CREATED SIZE snowchuai/centos-sshd latest ae717ca509d9 12 seconds ago 279 MB docker.io/centos latest 470671670cac 3 weeks ago 237 MB 8) 将容器sshd服务的22端口映射至本地2222端口 [root@docker1 ~]# docker run --name gzliu -h server1 -d -p 22222:22 snowchuai/centos-sshd /usr/sbin/sshd -D 4ba86e21944bcf579b8091c34da76131b9f0bfff6266cd63e9df5798234d563e [root@docker1 ~]# docker ps CONTAINER ID IMAGE COMMAND CREATED 3f94b148602e snowchuai/centos-sshd "/usr/sbin/sshd -D" 17 seconds ago STATUS PORTS NAMES Up 15 seconds 0.0.0.0:22222->22/tcp gzliu 9) 确认本地端口22222开放 [root@docker1 ~]# netstat -lantp | grep 22222 tcp6 0 0 :::22222 :::* LISTEN 3351/docker-proxy-c 10) 测试 [root@docker1 ~]# ssh root@127.0.0.1 -p 22222 The authenticity of host '[127.0.0.1]:22222 ([127.0.0.1]:22222)' can't be established. ECDSA key fingerprint is SHA256:7sg3oYSYESJmtzwXpUhNpbLl2pkqoeXX+s2hpbVE5OU. ECDSA key fingerprint is MD5:2d:d6:15:57:cc:da:9d:16:02:c5:a5:7c:f4:48:90:3f. Are you sure you want to continue connecting (yes/no)? yes Warning: Permanently added '[127.0.0.1]:22222' (ECDSA) to the list of known hosts. root@127.0.0.1's password: [root@server1 ~]#

3.2 创建带有http服务的Docker镜像

1) 开启一个新的容器,并在容器中安装ssh服务 [root@docker1 ~]# docker run --name snow -h snow -it centos /bin/bash [root@snow /]# yum install httpd -y 或 [root@snow /]# docker run centos /bin/bash -c "yum -y update; yum install httpd -y" 2) 做好服务的相关配置 [root@snow /]# echo "docker web page" > /var/www/html/index.html 3) 退出docker容器 [root@snow ~]# [^p][^q] 4) 获取DockerID或Docker名 [root@docker1 ~]# docker ps 5) 生成Docker镜像 [root@docker1 ~]# docker commit -m 'centos-httpd' fb8d7a7c2452 snowchuai/centos-httpd sha256:e35843943a72a11452048be9c7119e1e5914518b0f29c6485bf1daa5112f4923 [root@docker1 ~]# docker image list REPOSITORY TAG IMAGE ID CREATED SIZE snowchuai/centos-httpd latest e35843943a72 9 seconds ago 283 MB snowchuai/centos-sshd latest ae717ca509d9 25 minutes ago 279 MB docker.io/centos latest 470671670cac 3 weeks ago 237 MB 6) 将容器web服务的80端口映射至本地8088端口 [root@docker1 ~]# docker run --name websrv -h websrv1 -d -p 8088:80 snowchuai/centos-httpd /usr/sbin/httpd -DFOREGROUND 59a644b03b20cf1c49b69d6fbffe33719c026bcebc0f472a1433357cb541246e [root@docker1 ~]# docker ps CONTAINER ID IMAGE COMMAND CREATED 59a644b03b20 snowchuai/centos-httpd "/usr/sbin/httpd -..." 3 seconds ago STATUS PORTS NAMES Up 1 second 0.0.0.0:8088->80/tcp websrv 7) 确认本地端口8088开放 [root@docker1 ~]# lsof -i tcp:8088 COMMAND PID USER FD TYPE DEVICE SIZE/OFF NODE NAME docker-pr 3989 root 4u IPv6 63258 0t0 TCP *:radan-http (LISTEN) 8) 测试 [root@docker1 ~]# curl localhost:8088 docker httpd web page

3.3 自建Docker镜像

1) 首先瞄准一个linux,然后在虚拟机上装好 2) 调整Linux系统 3) 生成一个新的镜像 参数说明: --numeric-owner:以uid/gid方式记录文件的属主/属组 --exclude:排除范围 [root@c7 ~]# tar --numeric-owner --exclude=/proc --exclude=/sys --exclude=/tmp c7.tar / 4) 导入镜像 [root@docker1 ~]# cat c7.tar | docker import - linuxc7:laest

3.4 Docker镜像备份与恢复

1) 镜像备份 [root@docker1 ~]# docker images [root@docker1 ~]# docker save centos:latest > centos.tar 2) 恢复备份 [root@docker1 ~]# docker rmi centos:latest [root@docker1 ~]# docker images [root@docker1 ~]# docker load < centos.tar 3) 备份所有镜像 [root@docker1 ~]# docker save $(docker images | sed 1d | awk '{print $1}') > centos-all.tar [root@docker1 ~]# ls -lh centos-all.tar -rw-r--r-- 1 root root 318M Feb 8 17:16 centos-all.tar

4.1 Bridge模式实现

Bridge说明 bridge模式是docker的默认网络模式，默认通过本地主机docker0所包含的172.17.0.0/24网络段给docekr容器分配IP地址。不写--net参数，就是bridge模式。使用docker run -p时，docker实际是在iptables做了DNAT规则，实现端口转发功能。可以使用iptables -t nat -vnL查看。 +---------------------------------------------------------------------+ | +------------------------+ +------------------------+ | | | docker容器1 | | docker容器2 | | | +---------eth0-----------+ +----------eth0----------+ | | | | | |------------vethx-----------------------------------vethx------------| | | | | |------------------Local Host(docker0(172.17.0.1/24)------------------| | | | | | | | IP-Forwarding | | | | | | | +---------------------Local Host(eth0:192.168.10.21)------------------+ 1) 使用Bridge [root@docker1 ~]# docker rm -f $(docker ps -a | sed 1d | awk '{print $1}') [root@docker1 ~]# docker run -ti --name snow -h lisa --net=bridge centos /bin/bash [root@lisa /]# ip a s eth0 44: eth0@if45: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default link/ether 02:42:ac:11:00:02 brd ff:ff:ff:ff:ff:ff link-netnsid 0 inet 172.17.0.2/16 scope global eth0 valid_lft forever preferred_lft forever inet6 fe80::42:acff:fe11:2/64 scope link valid_lft forever preferred_lft forever 2) 确认 [root@docker1 ~]# brctl show bridge name bridge id STP enabled interfaces docker0 8000.0242e1b7b458 no veth99852aa [root@docker1 ~]# docker attach snow [root@lisa /]# ping -c 2 www.1000cc.net.cn PING www.1000cc.net.cn (122.51.252.99) 56(84) bytes of data. 64 bytes from 122.51.252.99 (122.51.252.99): icmp_seq=1 ttl=50 time=36.2 ms 64 bytes from 122.51.252.99 (122.51.252.99): icmp_seq=2 ttl=50 time=35.9 ms --- www.1000cc.net.cn ping statistics --- 2 packets transmitted, 2 received, 0% packet loss, time 60ms rtt min/avg/max/mdev = 35.892/36.064/36.236/0.172 ms 3) 查看容器的IP 语法: docker inspect --format '{{ .NetworkSettings.IPAddress }}' 容器ID/容器名 [root@docker1 ~]# docker inspect --format '{{ .NetworkSettings.IPAddress }}' snow 172.17.0.2 4) 查看所有容器IP [root@docker1 ~]# vim look-container-ip.sh #! /bin/bash name=$( docker ps | sed 1d | awk '{print $NF}') for nic in $name do ipaddr=`docker inspect --format '{{ .NetworkSettings.IPAddress }}' $nic` echo "$nic:$ipaddr" done [root@docker1 ~]# chmod 700 look-container-ip.sh [root@docker1 ~]# ./look-container-ip.sh gzliu:172.17.0.3 snow:172.17.0.2 5) 查看指定容器IP的脚本 [root@docker1 ~]# vim look-ip.sh #! /bin/bash for nic in $@ do cutip () { ipaddr=`docker inspect --format '{{ .NetworkSettings.IPAddress }}' $nic` echo "$nic: $ipaddr" } cutip done [root@docker1 ~]# chmod 700 look-ip.sh [root@docker1 ~]# ./look-ip.sh snow gzliu snow: 172.17.0.2 gzliu: 172.17.0.3

4.2 Host模式实现

Host说明 使用host模式，容器将不会获得一个独立的Network Namespace，而是和宿主机共用一个Network Namespace。容器将不会虚拟出自己的网卡，配置自己的IP等，而是使用宿主机的IP和端口。但是，容器的其他方面，如文件系统、进程列表等还是和宿主机隔离的。 +---------------------------------------------------------------------+ | +------------------------+ +------------------------+ | | | docker容器1 | | docker容器2 | | | +--eth0(192.168.10.xx)----+ +--eth0(192.168.10.xx)--+ | | | | | +---------------------Local Host(eth0:192.168.10.21)------------------+ 1) 实现host模式 [root@docker1 ~]# docker run -it --net=host --name lisa -h lisa centos /bin/bash 2) 验证 [root@lisa /]# ip a s eth0 2: eth0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP group default qlen 1000 link/ether 52:54:00:50:da:36 brd ff:ff:ff:ff:ff:ff inet 192.168.10.21/24 brd 192.168.10.255 scope global noprefixroute eth0 valid_lft forever preferred_lft forever inet6 fe80::bf48:bfc:a2b0:a8e6/64 scope link noprefixroute valid_lft forever preferred_lft forever [root@lisa /]# ping -c 2 www.1000cc.net.cn PING www.1000cc.net.cn (122.51.252.99) 56(84) bytes of data. 64 bytes from 122.51.252.99 (122.51.252.99): icmp_seq=1 ttl=51 time=37.0 ms 64 bytes from 122.51.252.99 (122.51.252.99): icmp_seq=2 ttl=51 time=36.1 ms --- www.1000cc.net.cn ping statistics --- 2 packets transmitted, 2 received, 0% packet loss, time 3ms rtt min/avg/max/mdev = 36.149/36.582/37.016/0.473 ms

4.3 Container模式实现

Container说明 1. Container模式指定新创建的容器和已经存在的一个容器共享一个 Network Namespace，而不是和宿主机共享。 2. 新创建的容器不会创建自己的网卡，配置自己的 IP，而是和一个指定的容器共享 IP、端口范围等。 3. 同样，两个容器除了网络方面，其他的如文件系统、进程列表等还是隔离的。两个容器的进程可以通过 lo 网卡设备通信。。 +----------------------------------------------------------------------+ | +-----------------------+ +-----------------------+ | | | docker容器1 +--(共享eth0)--+ docker容器2 | | | +-----------------------+ | +-----------------------+ | | | | |---------------------------------vethx--------------------------------| | | | |------------------Local Host(docker0(172.17.0.1/24)-------------------| | | | | | | | IP-Forwarding | | | | | | | +---------------------Local Host(eth0:192.168.10.21)-------------------+ 1) 实现Container模式 (1) 启动一个容器,网络模式为Bridge [root@docker1 ~]# docker rm -f $(docker ps -a | sed 1d | awk '{print $1}') [root@docker1 ~]# docker run -tid --name gzliu -h gzlau --net=bridge centos /bin/bash [root@docker1 ~]# docker inspect --format '{{ .NetworkSettings.IPAddress }}' gzliu 172.17.0.2 (2) 实现Container网络模式 [root@docker1 ~]# docker run -it --net=container:gzliu --name snowchuai centos /bin/bash [root@gzlau /]# ip a s eth0 # 注意,以关联到gzlau容器 50: eth0@if51: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default link/ether 02:42:ac:11:00:02 brd ff:ff:ff:ff:ff:ff link-netnsid 0 inet 172.17.0.2/16 scope global eth0 valid_lft forever preferred_lft forever inet6 fe80::42:acff:fe11:2/64 scope link valid_lft forever preferred_lft forever

4.4 None模式实现

Container说明 1. none模式，Docker容器拥有自己的Network Namespace，但是，并不为Docker容器进行任何网络配置。 2. 这个Docker容器没有网卡、IP、路由等信息。需要我们自己为Docker容器添加网卡、配置IP。 +----------------------------------------------------------------------+ | +-----------------------+ +-----------------------+ | | | docker容器1 | | docker容器2 | | | +-----------------------+ +-----------------------+ | | | | | | | +---------------------Local Host(eth0:192.168.10.21)-------------------+ 1) 实现None网络模式 [root@docker1 ~]# docker run -ti --net=none --name c7 centos /bin/bash [root@673082ca2fc5 /]# ip a s 1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000 link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00 inet 127.0.0.1/8 scope host lo valid_lft forever preferred_lft forever inet6 ::1/128 scope host valid_lft forever preferred_lft forever

4.5 为docker容器添加网络段并指定IP地址

# 仅允许在自定义网络上指定IP,不允许在默认的网络(Bridge)指定IP [root@docker1 ~]# docker network create --driver bridge --subnet=172.22.0.0/16 --gateway=172.22.0.1 1000y 577593accc9ff1b72163da7661964351f9c95ee07abee7d1bfdff6cbf8c6ee53 [root@sdocker ~]# docker network ls NETWORK ID NAME DRIVER SCOPE 577593accc9f 1000y bridge local 975cbfa47932 bridge bridge local 0aee05d74865 host host local e44aca320f04 none null local [root@docker1 ~]# docker network inspect 1000y # 以下为输出内容 [ { "Name": "1000y", "Id": "577593accc9ff1b72163da7661964351f9c95ee07abee7d1bfdff6cbf8c6ee53", "Created": "2020-07-21T03:35:29.345620264+08:00", "Scope": "local", "Driver": "bridge", "EnableIPv6": false, "IPAM": { "Driver": "default", "Options": {}, "Config": [ { "Subnet": "172.22.0.0/16", "Gateway": "172.22.0.1" } ] }, "Internal": false, "Attachable": false, "Ingress": false, "ConfigFrom": { "Network": "" }, "ConfigOnly": false, "Containers": {}, "Options": {}, "Labels": {} } ] [root@docker1 ~]# docker run -itd --net=1000y --ip 172.22.0.222 --name lisa -h lisa centos /bin/bash [root@docker1 ~]# docker inspect lisa | grep IPv4 "IPv4Address": "172.22.0.222"

5.1 直接路由

+--------------------------------+ +--------------------------------+ | +------------------------+ | | +------------------------+ | | | docker容器1 | | | | docker容器2 | | | +---------eth0-----------+ | | +----------eth0----------+ | | | | | | | |------------vethx---------------| |------------vethx---------------| | | | | | | |-----docker0(172.16.1.1/24)-----+ |-----docker0(172.16.2.1/24)-----+ | | | | | | | | | | | | | IP-Forwarding | | IP-Forwarding | | | | | | | | | | | | | +-Local Host(eth0:192.168.10.21)-+ +-Local Host(eth0:192.168.10.22)-+ | | | | | +---------------+ | +----------| Switch |-----------+ +---------------+ 1) 修改各个docker主机的配置 (1) docker版本 [root@docker1 ~]# vim /etc/sysconfig/docker-network DOCKER_NETWORK_OPTIONS="--bip=172.16.1.1/24" [root@docker1 ~]# systemctl restart docker (2) docker-ce版本 [root@docker1 ~]# vim /etc/docker/daemon.json { "registry-mirrors": ["https://3laho3y3.mirror.aliyuncs.com"], "bip": "172.16.1.1/24" } [root@docker1 ~]# systemctl restart docker # 设定路由及追加防火墙规则 [root@docker1 ~]# route add -net 172.16.2.0/24 gw 192.168.10.22 [root@docker1 ~]# iptables -t nat -F POSTROUTING [root@docker1 ~]# iptables -t nat -A POSTROUTING -s 172.16.1.0/24 ! -d 172.16.0.0/16 -j MASQUERADE [root@docker1 ~]# iptables -A FORWARD -s 172.16.2.0/24 -d 172.16.1.0/24 -j ACCEPT [root@docker1 ~]# ip a s docker0 3: docker0: <NO-CARRIER,BROADCAST,MULTICAST,UP> mtu 1500 qdisc noqueue state DOWN group default link/ether 02:42:8a:4d:e9:10 brd ff:ff:ff:ff:ff:ff inet 172.16.1.1/24 scope global docker0 valid_lft forever preferred_lft forever ######### docker2节点设置 (1) docker [root@docker2 ~]# vim /etc/sysconfig/docker-network DOCKER_NETWORK_OPTIONS="--bip=172.16.2.1/24" [root@docker2 ~]# systemctl restart docker (2) docker-ce版本 [root@docker2 ~]# vim /etc/docker/daemon.json { "registry-mirrors": ["https://3laho3y3.mirror.aliyuncs.com"], "bip": "172.16.2.1/24" } [root@docker2 ~]# systemctl restart docker # 设定路由及追加防火墙规则 [root@docker2 ~]# route add -net 172.16.1.0/24 gw 192.168.10.21 [root@docker2 ~]# iptables -t nat -F POSTROUTING [root@docker2 ~]# iptables -t nat -A POSTROUTING -s 172.16.2.0/24 ! -d 172.16.0.0/16 -j MASQUERADE [root@docker2 ~]# iptables -A FORWARD -s 172.16.1.0/24 -d 172.16.2.0/24 -j ACCEPT [root@docker2 ~]# ip a s docker0 3: docker0: <NO-CARRIER,BROADCAST,MULTICAST,UP> mtu 1500 qdisc noqueue state DOWN group default link/ether 02:42:62:8c:1a:df brd ff:ff:ff:ff:ff:ff inet 172.16.2.1/24 scope global docker0 valid_lft forever preferred_lft forever 2) 各个docker启动一个容器,并确认容器的IP [root@docker1 ~]# docker run -it --name snow -h snow centos /bin/bash [root@snow /]# ip a s eth0 4: eth0@if5: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default link/ether 02:42:c0:a8:bc:02 brd ff:ff:ff:ff:ff:ff link-netnsid 0 inet 172.16.1.2/24 scope global eth0 valid_lft forever preferred_lft forever inet6 fe80::42:c0ff:fea8:bc02/64 scope link valid_lft forever preferred_lft forever [root@docker2 ~]# docker run -it --name gzliu -h gz centos /bin/bash [root@gz /]# ip a s eth0 4: eth0@if5: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default link/ether 02:42:c0:a8:bd:02 brd ff:ff:ff:ff:ff:ff link-netnsid 0 inet 172.16.2.2/24 scope global eth0 valid_lft forever preferred_lft forever inet6 fe80::42:c0ff:fea8:bd02/64 scope link valid_lft forever preferred_lft forever 3) 测试 让docker1主机上的容器ping通docker2主机上的容器 [root@snow /]# ping -c 2 172.16.2.2 PING 172.16.2.2 (172.16.2.2) 56(84) bytes of data. 64 bytes from 172.16.2.2: icmp_seq=1 ttl=62 time=0.779 ms 64 bytes from 172.16.2.2: icmp_seq=2 ttl=62 time=0.686 ms --- 172.16.2.2 ping statistics --- 2 packets transmitted, 2 received, 0% packet loss, time 2ms rtt min/avg/max/mdev = 0.686/0.732/0.779/0.053 ms

5.2 Pipework实现网络通信

+--------------------------------+ +--------------------------------+ | +------------------------+ | | +------------------------+ | | | docker容器1 | | | | docker容器2 | | | +---------eth0-----------+ | | +----------eth0----------+ | | | | | | | |------------vethx---------------| |------------vethx---------------| | | | | | | |-------br0(172.16.1.1/24)-------+ |-------br0(172.16.1.1/24)-------+ | | | | | | | | | | | | | | | | | | +-Local Host(eth0:192.168.10.21)-+ +-Local Host(eth0:192.168.10.22)-+ | | | | | +---------------+ | +----------| Switch |-----------+ +---------------+ 1) 设置br0桥接设备 (1) 为docker1主机设置br0 [root@docker1 ~]# nmcli connection add type bridge autoconnect yes con-name br0 ifname br0 Connection 'br0' (491dd4da-1641-4ff2-bf5b-17a928d700d1) successfully added. [root@docker1 ~]# nmcli connection modify br0 ipv4.addresses 192.168.10.121/24 ipv4.method manual [root@docker1 ~]# nmcli connection modify br0 ipv4.gateway 192.168.10.1 [root@docker1 ~]# nmcli connection modify br0 ipv4.dns 114.114.114.114 # 将eth0加入至br0中 [root@docker1 ~]# nmcli connection delete eth0 Connection 'eth0' (43e81ba8-5171-4ca6-ae34-58c64d73d9a9) successfully deleted. [root@docker1 ~]# nmcli connection add type bridge-slave autoconnect yes con-name eth0 ifname eth0 master br0 Connection 'eth0' (b3eea871-56c1-4cfb-a57b-d7df454ee8a8) successfully added. [root@docker1 ~]# nmcli device disconnect br0 Device 'br0' successfully disconnected. [root@docker1 ~]# nmcli device connect eth0 Device 'eth0' successfully activated with 'b3eea871-56c1-4cfb-a57b-d7df454ee8a8'. [root@docker1 ~]# ip a s br0 9: br0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default qlen 1000 link/ether 52:54:00:13:3c:d4 brd ff:ff:ff:ff:ff:ff inet 192.168.10.121/24 brd 192.168.10.255 scope global noprefixroute br0 valid_lft forever preferred_lft forever inet6 fe80::f855:966f:1de9:eed6/64 scope link noprefixroute valid_lft forever preferred_lft forever (2) 为docker2主机设置br0 [root@docker2 ~]# nmcli connection add type bridge autoconnect yes con-name br0 ifname br0 [root@docker2 ~]# nmcli connection modify br0 ipv4.addresses 192.168.10.122/24 ipv4.method manual [root@docker2 ~]# nmcli connection modify br0 ipv4.gateway 192.168.10.1 [root@docker2 ~]# connection modify br0 ipv4.dns 114.114.114.114 # 将eth0加入至br0中 [root@docker2 ~]# nmcli connection delete eth0 [root@docker2 ~]# nmcli connection add type bridge-slave autoconnect yes con-name eth0 ifname eth0 master br0 [root@docker2 ~]# nmcli device disconnect br0 [root@docker2 ~]# nmcli device connect eth0 [root@docker2 ~]# ip a s br0 9: br0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default qlen 1000 link/ether 52:54:00:13:3c:d4 brd ff:ff:ff:ff:ff:ff inet 192.168.10.122/24 brd 192.168.10.255 scope global noprefixroute br0 valid_lft forever preferred_lft forever inet6 fe80::f855:966f:1de9:eed6/64 scope link noprefixroute valid_lft forever preferred_lft forever 2) 修改各个docker主机的配置 (1) docker版 [root@docker1 ~]# vim /etc/sysconfig/docker-network DOCKER_NETWORK_OPTIONS="-b=br0" [root@docker1 ~]# systemctl restart docker [root@docker2 ~]# vim /etc/sysconfig/docker-network DOCKER_NETWORK_OPTIONS="-b=br0" [root@docker2 ~]# systemctl restart docker (2) docker-ce版 [root@docker1 ~]# vim /etc/docker/daemon.json { "registry-mirrors": ["https://3laho3y3.mirror.aliyuncs.com"], "bridge": "br0" } [root@docker1 ~]# systemctl restart docker [root@docker2 ~]# vim /etc/docker/daemon.json { "registry-mirrors": ["https://3laho3y3.mirror.aliyuncs.com"], "bridge": "br0" } [root@docker2 ~]# systemctl restart docker 2) 下载pipework [root@docker1 ~]# yum install git -y [root@docker1 ~]# git clone https://github.com/jpetazzo/pipework [root@docker1 ~]# cp pipework/pipework /usr/local/bin/ [root@docker2 ~]# yum install git -y [root@docker2 ~]# git clone https://github.com/jpetazzo/pipework [root@docker2 ~]# cp pipework/pipework /usr/local/bin/ 3) 生成容器,并使用none网络模式 [root@docker1 ~]# docker run -it --net=none --name snow -h snow centos /bin/bash [root@snow /]# ip a s 1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000 link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00 inet 127.0.0.1/8 scope host lo valid_lft forever preferred_lft forever inet6 ::1/128 scope host valid_lft forever preferred_lft forever [root@snow /]# [^p][^q] [root@docker2 ~]# docker run -it --net=none --name gzliu -h gz centos /bin/bash [root@gz /]# ip a s 1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000 link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00 inet 127.0.0.1/8 scope host lo valid_lft forever preferred_lft forever inet6 ::1/128 scope host valid_lft forever preferred_lft forever [root@gz /]# [^p][^q] 4) 给容器分配IP (1) docker1主机配置 # 语法: pipework br0 容器ID/Name 所分配的IP/子网@网关 [root@docker1 ~]# pipework br0 snow 192.168.10.123/24@192.168.10.1 [root@docker1 ~]# docker attach snow [root@snow /]# ip a s eth1 7: eth1@if8: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default qlen 1000 link/ether 52:29:53:db:41:5a brd ff:ff:ff:ff:ff:ff link-netnsid 0 inet 192.168.10.123/24 brd 192.168.10.255 scope global eth1 valid_lft forever preferred_lft forever inet6 fe80::5029:53ff:fedb:415a/64 scope link valid_lft forever preferred_lft forever [root@snow /]# ip r s default via 192.168.10.1 dev eth1 192.168.10.0/24 dev eth1 proto kernel scope link src 192.168.10.123 # 如果网络中有DHCP服务，可让pipwork给容器通过dhcp服务分配IP地址 [root@docker1 ~]# pipework br0 snow dhcp (2) docker2主机配置 # 语法: pipework br0 容器ID/Name 所分配的IP/子网@网关 [root@docker1 ~]# pipework br0 gzliu 192.168.10.124/24@192.168.10.1 [root@docker1 ~]# docker attach gzliu [root@gz /]# ip a s eth1 11: eth1@if12: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default qlen 1000 link/ether de:f5:e9:85:ea:19 brd ff:ff:ff:ff:ff:ff link-netnsid 0 inet 192.168.10.124/24 brd 192.168.10.255 scope global eth1 valid_lft forever preferred_lft forever inet6 fe80::dcf5:e9ff:fe85:ea19/64 scope link valid_lft forever preferred_lft forever [root@gz /]# ip r s default via 192.168.10.1 dev eth1 192.168.10.0/24 dev eth1 proto kernel scope link src 192.168.10.124 5) 测试 [root@snow /]# ping -c 2 192.168.10.124 PING 192.168.10.124 (192.168.10.124) 56(84) bytes of data. 64 bytes from 192.168.10.124: icmp_seq=1 ttl=64 time=0.726 ms 64 bytes from 192.168.10.124: icmp_seq=2 ttl=64 time=0.624 ms --- 192.168.10.124 ping statistics --- 2 packets transmitted, 2 received, 0% packet loss, time 2ms rtt min/avg/max/mdev = 0.624/0.675/0.726/0.051 ms

5.3 Flannel网络实现

5.3.1 Flannel网络拓扑说明

+--------------------------------+ +--------------------------------+ | docker1.1000cc.net | | docker1.1000cc.net | | Docker(含容器） | | Docker(含容器) | | Etcd. Flannel | | Flannel | +------(eth0:192.168.10.21)------+ +------(eth0:192.168.10.22)------+ | | +--------------------------------------+ 如果跟随上面实验完成到此，请先删除br0

5.3.2 实现Flannel网络--主控节点

1) 配置hosts文件 [root@docker1 ~]# vim /etc/hosts ...... ...... ...... ...... ...... ...... 192.168.10.21 docker1.1000cc.net 192.168.10.21 etcd 192.168.10.22 docker2.1000cc.net [root@docker1 ~]# scp /etc/hosts root@192.168.10.22:/etc/ hosts 100% 244 200.1KB/s 00:00 2) 安装及配置etcd [root@docker1 ~]# yum install -y etcd [root@docker1 ~]# cp /etc/etcd/etcd.conf /etc/etcd/etcd.conf.bak [root@docker1 ~]# vim /etc/etcd/etcd.conf ...... ...... ...... ...... ...... ...... # 修改第3行为以下内容 ETCD_DATA_DIR="/var/lib/etcd/default.etcd" ...... ...... ...... ...... ...... ...... # 修改第6行,设定监听客户端地址 ETCD_LISTEN_CLIENT_URLS="http://0.0.0.0:2379,http://0.0.0.0:4001" ...... ...... ...... ...... ...... ...... # 修改第9行 ETCD_NAME=master ...... ...... ...... ...... ...... ...... # 修改21行,设置通知客户端 ETCD_ADVERTISE_CLIENT_URLS="http://etcd:2379,http://etcd:4001" ...... ...... ...... ...... ...... ...... [root@docker1 ~]# systemctl enable --now etcd 3) 测试etcd # 设置相关key及value，并测试是否能够返回值 [root@docker1 ~]# etcdctl set testdir/testkey0 0 0 [root@docker1 ~]# etcdctl get testdir/testkey0 0 # etcd健康检查 [root@docker1 ~]# etcdctl -C http://etcd:4001 cluster-health member 8e9e05c52164694d is healthy: got healthy result from http://etcd:2379 cluster is healthy [root@docker1 ~]# etcdctl -C http://etcd:2379 cluster-health member 8e9e05c52164694d is healthy: got healthy result from http://etcd:2379 cluster is healthy 4) 安装Flannel [root@docker1 ~]# yum install flannel -y 5) 配置Flannel [root@docker1 ~]# cp /etc/sysconfig/flanneld /etc/sysconfig/flanneld.bak [root@docker1 ~]# vim /etc/sysconfig/flanneld ...... ...... ...... ...... ...... ...... # 将第4行、第8行改为如下内容 FLANNEL_ETCD_ENDPOINTS="http://etcd:2379" ...... ...... ...... ...... ...... ...... FLANNEL_ETCD_PREFIX="/1000cc.io/network" 6) 配置Flannel key [root@docker1 ~]# etcdctl --endpoints http://etcd:2379 set /1000cc.io/network/config '{"Network": "172.16.0.0/16"}' {"Nework":"172.16.0.0/16"} 7) 启动Flannel服务 [root@docker1 ~]# systemctl enable --now flanneld.service 8) 重启docker服务 # 将/etc/sysconfig/docker-network里面的值删除 # 将/run/flannel/docker文件中"DOCKER_NETWORK_OPTIONS="值删除 [root@docker1 ~]# systemctl restart docker 9) 确认接口信息 [root@docker1 ~]# ip a s ...... ...... ...... ...... ...... ...... 4: flannel0: <POINTOPOINT,MULTICAST,NOARP,UP,LOWER_UP> mtu 1472 qdisc pfifo_fast state UNKNOWN group default qlen 500 link/none inet 172.16.72.0/16 scope global flannel0 valid_lft forever preferred_lft forever inet6 fe80::2348:9f6d:f9ac:f80b/64 scope link flags 800 valid_lft forever preferred_lft forever 5: docker0: <NO-CARRIER,BROADCAST,MULTICAST,UP> mtu 1500 qdisc noqueue state DOWN group default link/ether 02:42:f0:69:69:bf brd ff:ff:ff:ff:ff:ff inet 172.16.72.1/24 scope global docker0 valid_lft forever preferred_lft forever

5.3.3 被控节点

1) 配置完成/etc/hosts解析文件 2) 安装Flannel [root@docker2 ~]# yum install flannel -y 3) 配置Flannel [root@docker2 ~]# cp /etc/sysconfig/flanneld /etc/sysconfig/flanneld.bak [root@docker2 ~]# vim /etc/sysconfig/flanneld # 将第4行、第8行改为如下内容 ...... ...... ...... ...... ...... ...... FLANNEL_ETCD_ENDPOINTS="http://etcd:2379" ...... ...... ...... ...... ...... ...... FLANNEL_ETCD_PREFIX="/1000cc.io/network" 4) 启动Flannel服务 [root@docker2 ~]# systemctl enable --now flanneld.service 5) 重启docker服务 # 将/etc/sysconfig/docker-network里面的值删除 # 将/run/flannel/docker文件中"DOCKER_NETWORK_OPTIONS="值删除 [root@docke2 ~]# systemctl restart docker 6) 确认接口信息 [root@docker2 ~]# systemctl restart docker [root@docker2 ~]# ip a s 4: flannel0: <POINTOPOINT,MULTICAST,NOARP,UP,LOWER_UP> mtu 1472 qdisc pfifo_fast state UNKNOWN group default qlen 500 link/none inet 172.16.28.0/16 scope global flannel0 valid_lft forever preferred_lft forever inet6 fe80::7b7c:c37a:417e:c282/64 scope link flags 800 valid_lft forever preferred_lft forever 5: docker0: <NO-CARRIER,BROADCAST,MULTICAST,UP> mtu 1500 qdisc noqueue state DOWN group default link/ether 02:42:41:e7:de:f7 brd ff:ff:ff:ff:ff:ff inet 172.16.28.1/24 scope global docker0 valid_lft forever preferred_lft forever

5.3.4 验证通信

(1) Docker1主机启动容器并确认Ip地址 [root@docker1 ~]# docker run -it --name snow -h snowchuai centos /bin/bash [root@snowchuai /]# ip a s ...... ...... ...... ...... ...... ...... 6: eth0@if7: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default link/ether 02:42:ac:11:00:02 brd ff:ff:ff:ff:ff:ff link-netnsid 0 inet 172.16.72.2/24 scope global eth0 valid_lft forever preferred_lft forever inet6 fe80::42:acff:fe11:2/64 scope link tentative valid_lft forever preferred_lft forever (3) Docker2主机启动容器并确认IP地址 [root@docker2 ~]# docker run -it --name gz -h gzliu centos /bin/bash [root@gzliu /]# ip a s ...... ...... ...... ...... ...... ...... 6: eth0@if7: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default link/ether 02:42:ac:11:00:02 brd ff:ff:ff:ff:ff:ff link-netnsid 0 inet 172.16.28.2/24 scope global eth0 valid_lft forever preferred_lft forever inet6 fe80::42:acff:fe11:2/64 scope link tentative valid_lft forever preferred_lft forever (3) 外网访问测试 [root@snowchuai /]# ping -c 2 www.1000cc.net PING 1000cc.net.cn (122.51.252.99) 56(84) bytes of data. 64 bytes from 122.51.252.99 (122.51.252.99): icmp_seq=1 ttl=50 time=37.1 ms 64 bytes from 122.51.252.99 (122.51.252.99): icmp_seq=2 ttl=50 time=35.6 ms --- 1000cc.net.cn ping statistics --- 2 packets transmitted, 2 received, 0% packet loss, time 56ms rtt min/avg/max/mdev = 35.649/36.354/37.060/0.730 m [root@gzliu /]# ping -c 2 www.1000cc.net PING 1000cc.net.cn (122.51.252.99) 56(84) bytes of data. 64 bytes from 122.51.252.99 (122.51.252.99): icmp_seq=1 ttl=50 time=38.4 ms 64 bytes from 122.51.252.99 (122.51.252.99): icmp_seq=2 ttl=50 time=37.9 ms --- 1000cc.net.cn ping statistics --- 2 packets transmitted, 2 received, 0% packet loss, time 2ms rtt min/avg/max/mdev = 37.880/38.135/38.391/0.321 ms (4) 内网访问测试 [root@docker1 ~]# iptables -P FORWARD ACCEPT [root@docker2 ~]# iptables -P FORWARD ACCEPT [root@snowchuai /]# ping -c 2 172.16.28.2 PING 172.16.28.2 (172.16.28.2) 56(84) bytes of data. 64 bytes from 172.16.28.2: icmp_seq=1 ttl=60 time=1.50 ms 64 bytes from 172.16.28.2: icmp_seq=2 ttl=60 time=1.14 ms --- 172.16.28.2 ping statistics --- 2 packets transmitted, 2 received, 0% packet loss, time 3ms rtt min/avg/max/mdev = 1.141/1.321/1.501/0.180 ms [root@gzliu /]# ping -c 2 172.16.72.2 PING 172.16.72.2 (172.16.72.2) 56(84) bytes of data. 64 bytes from 172.16.72.2: icmp_seq=1 ttl=60 time=1.68 ms 64 bytes from 172.16.72.2: icmp_seq=2 ttl=60 time=1.05 ms --- 172.16.72.2 ping statistics --- 2 packets transmitted, 2 received, 0% packet loss, time 3ms rtt min/avg/max/mdev = 1.048/1.362/1.676/0.314 ms

6.1 将本地目录挂载至容器中

1) 为容器创建一个数据卷--volume模式 [root@srv1 ~]# docker volume create nginx-vol nginx-vol [root@srv1 ~]# docker volume ls DRIVER VOLUME NAME local nginx-vol [root@srv1 ~]# docker volume inspect nginx-vol [ { "Driver": "local", "Labels": {}, "Mountpoint": "/var/lib/docker/volumes/nginx-vol/_data", "Name": "nginx-vol", "Options": {}, "Scope": "local" } ] [root@srv1 ~]# docker run -d --name=websrv -h websrv -p 80:80 -v nginx-vol:/usr/share/nginx/html nginx dbd57aba999e640124ab5c381a5fd27f3023dbbaee8d9c1018ab770aaea7f169 [root@srv1 ~]# echo "hello world" > /var/lib/docker/volumes/nginx-vol/_data/index.html 2) 为容器创建一个savedisk目录---mount bind模式 [root@docker1 ~]# docker run -it --name snow -h snowchuai -v /savedisk centos /bin/bash [root@snowchuai /]# ls -ld /savedisk drwxr-xr-x 2 root root 4096 Feb 8 17:00 /savedisk 3) 将主机目录/docker-disk挂载至容器的/mnt目录 [root@docker1 ~]# mkdir /docker-disk [root@docker1 ~]# touch /docker-disk/test.txt [root@docker1 ~]# docker run -it --name snow -h snowchuai -v /docker-disk:/mnt centos /bin/bash [root@snowchuai /]# ls -l /mnt/ total 0 -rw-r--r-- 1 root root 0 Feb 8 16:53 test.txt [root@snowchuai /]# touch /mnt/abc.txt [root@snowchuai /]# exit [root@docker1 ~]# ls -l /docker-disk/ total 0 -rw-r--r-- 1 root root 0 Feb 9 00:55 a.txt -rw-r--r-- 1 root root 0 Feb 9 00:53 test.txt 4) 将主机目录/docker-disk挂载至容器的/mnt目录,并设置为"只读"权限 [root@docker1 ~]# docker run -it --name snow -h snowchuai -v /docker-disk:/mnt:ro centos /bin/bash [root@snowchuai /]# touch /mnt/xyz.txt touch: cannot touch '/mnt/xyz.txt': Read-only file system

6.2 容器间共享数据卷

1) 容器间共享卷 (1) 生成第1个容器:snow,并挂载主机本地目录/docker-disk至容器/mnt下 [root@docker1 ~]# docker run -it --name snow -h snowchuai -v /docker-disk:/mnt centos /bin/bash [root@snowchuai /]# ls -l /mnt/ total 0 -rw-r--r-- 1 root root 0 Feb 8 16:55 a.txt -rw-r--r-- 1 root root 0 Feb 8 16:53 test.txt (2) 生成第2个容器:lisa,并挂载容器snow的卷 [root@docker1 ~]# docker run -it --name lisa -h lisa --volumes-from snow centos /bin/bash [root@lisa /]# ls -l /mnt/ total 0 -rw-r--r-- 1 root root 0 Feb 8 16:55 a.txt -rw-r--r-- 1 root root 0 Feb 8 16:53 test.txt (3) 挂载其他容器卷的同时挂载本地目录 [root@docker1 ~]# docker run -it --name gz -h gzliu --volumes-from snow -v /tmp:/savedisk centos /bin/bash (4) 卷的备份 [root@docker1 ~]# docker run -it --name snow -h snowchuai -v /docker-disk:/mnt centos tar cfpz /mnt/etc.tgz /etc [root@docker1 ~]# ls -l /docker-disk/etc.tgz -rw-r--r-- 1 root root 800837 Feb 9 01:25 /docker-disk/etc.tgz (5) 恢复备份 [root@docker1 ~]# mkdir -v /data [root@docker1 ~]# docker run -itd --name snow -h snowchuai -v /data/:/data centos /bin/bash [root@docker1 ~]# docker run -it --name gz -h gzliu --volumes-from snow -v /docker-disk/:/backup centos tar xvfz /backup/etc.tgz -C /data [root@docker1 ~]# ls -l /data total 4 drwxr-xr-x 51 root root 4096 Feb 9 01:25 etc

7.1 建立私有仓库

1) 下载docker的仓库镜像 [root@docker1 ~]# docker pull registry [root@docker1 ~]# docker images REPOSITORY TAG IMAGE ID CREATED SIZE snowchuai/centos-httpd latest 5c087779ee61 9 hours ago 283 MB snowchuai/centos-sshd latest ae717ca509d9 9 hours ago 279 MB docker.io/registry latest 708bc6af7e5e 2 weeks ago 25.8 MB docker.io/centos latest 470671670cac 3 weeks ago 237 MB 2) 建立私有仓库 [root@docker1 ~]# docker run -idt --restart=always \ --name registry -v /opt/registry:/var/lib/registry \ -p 5000:5000 registry e0860472aa25387698c73feebed06e281543f589620f2027c0c6261804192a43 3) 在docker1客户端配置私有docker仓库 (1) docker版本 [root@docker1 ~]# vim /etc/sysconfig/docker OPTIONS='--insecure-registry docker1.1000cc.net:5000 --selinux-enabled --log-driver=journald.....' [root@docker1 ~]# systemctl restart docker (2) docker-ce版本 [root@docker1 ~]# vim /etc/docker/daemon.json { "registry-mirrors": ["https://3laho3y3.mirror.aliyuncs.com"], "insecure-registries": ["docker1.1000y.net:5000"] } [root@docker1 ~]# systemctl restart docker 5) 给镜像打tag [root@docker1 ~]# docker images REPOSITORY TAG IMAGE ID CREATED SIZE snowchuai/centos-httpd latest 5c087779ee61 9 hours ago 283 MB snowchuai/centos-sshd latest ae717ca509d9 9 hours ago 279 MB docker.io/registry latest 708bc6af7e5e 2 weeks ago 25.8 MB docker.io/centos latest 470671670cac 3 weeks ago 237 MB [root@docker1 ~]# docker tag snowchuai/centos-sshd docker1.1000cc.net:5000/centos-sshd [root@docker1 ~]# docker images REPOSITORY TAG IMAGE ID CREATED SIZE snowchuai/centos-httpd latest 5c087779ee61 9 hours ago 283 MB docker1.1000cc.net:5000/centos-sshd latest ae717ca509d9 10 hours ago 279 MB snowchuai/centos-sshd latest ae717ca509d9 10 hours ago 279 MB docker.io/registry latest 708bc6af7e5e 2 weeks ago 25.8 MB docker.io/centos latest 470671670cac 3 weeks ago 237 MB 6) 上传镜像至私有仓库 [root@docker1 ~]# docker push docker1.1000cc.net:5000/centos-sshd The push refers to a repository [docker1.1000cc.net:5000/centos-sshd] 6eb13f7822dd: Pushed 0683de282177: Pushed latest: digest: sha256:d2fa4f352f2c5de6174ad71cc89c8a4c6fc890d3ecad632d9b7c82cc5f8a628a size: 741 7) 查询私有仓库镜像 [root@docker1 ~]# curl -XGET http://docker1.1000cc.net:5000/v2/_catalog {"repositories":["centos-sshd"]} 8) 查询私有仓库镜像tags列表 [root@docker1 ~]# curl -XGET http://docker1.1000cc.net:5000/v2/centos-sshd/tags/list {"name":"centos-sshd","tags":["latest"]} 9) 测试私有仓库镜像 [root@docker1 ~]# docker rmi docker1.1000cc.net:5000/centos-sshd Untagged: docker1.1000cc.net:5000/centos-sshd:latest Untagged: docker1.1000cc.net:5000/centos-sshd@sha256:d2fa4f352f2c5de6174ad71cc89c8a4c6fc890d3ecad632d9b7c82cc5f8a628a [root@docker1 ~]# docker pull docker1.1000cc.net:5000/centos-sshd Using default tag: latest Trying to pull repository docker1.1000cc.net:5000/centos-sshd ... latest: Pulling from docker1.1000cc.net:5000/centos-sshd Digest: sha256:d2fa4f352f2c5de6174ad71cc89c8a4c6fc890d3ecad632d9b7c82cc5f8a628a Status: Downloaded newer image for docker1.1000cc.net:5000/centos-sshd:latest [root@docker1 ~]# docker run -it --name test docker1.1000cc.net:5000/centos-sshd /bin/bash [root@d940054d57fb /]#

7.2 建立带有SSL的私有仓库

1) 创建一个证书 [root@docker1 ~]# mkdir -p /opt/docker/registry/certs [root@docker1 ~]# openssl genrsa -aes128 2048 > /opt/docker/registry/certs/domain.key [root@docker1 ~]# openssl rsa -in /opt/docker/registry/certs/domain.key -out /opt/docker/registry/certs/domain.key [root@docker1 ~]# openssl req -utf8 -new -key /opt/docker/registry/certs/domain.key -out /opt/docker/registry/certs/domain.csr Generating a 4096 bit RSA private key ................................................................ ................................................................ ................................................................ ................................................................ ........................................................++ .....................................................++ writing new private key to '/opt/docker/registry/certs/domain.key' ----- You are about to be asked to enter information that will be incorporated into your certificate request. What you are about to enter is what is called a Distinguished Name or a DN. There are quite a few fields but you can leave some blank For some fields there will be a default value, If you enter '.', the field will be left blank. ----- Country Name (2 letter code) [XX]:CN State or Province Name (full name) []:BeiJing Locality Name (eg, city) [Default City]:BeiJing Organization Name (eg, company) [Default Company Ltd]:1000cc.net Organizational Unit Name (eg, section) []:tech Common Name (eg, your name or your server's hostname) []:docker1.1000cc.net Email Address []: [root@docker1 /etc/pki/tls/certs]# vim /etc/pki/tls/openssl.cnf ...... ...... ...... ...... ...... ...... # 于文件最后追加如下内容 [ 1000y.cloud ] subjectAltName = DNS:docker1.1000y.net, IP:192.168.1.11 [root@docker1 ~]# openssl x509 -in /opt/docker/registry/certs/domain.csr \ -out /opt/docker/registry/certs/domain.crt \ -req -signkey /opt/docker/registry/certs/domain.key -days 365 \ -extfile /etc/pki/tls/openssl.cnf -extensions 1000y.cloud 2) 让registry容器启动并增加SSL [root@docker1 ~]# docker run -itd --restart=always \ --name registry -v /opt/registry/:/var/lib/registry \ -v /opt/docker/registry/certs:/certs -p 5000:5000 \ -e REGISTRY_HTTP_TLS_CERTIFICATE=/certs/domain.crt \ -e REGISTRY_HTTP_TLS_KEY=/certs/domain.key registry 91daadaaec4e733ac9439131592e9f69b77e8b9ac53dba0fe2efa18efc67f924 3) 客户端准备存放证书的路径,并将crt证书复制到客户端 [root@docker2 ~]# mkdir -p /etc/docker/certs.d/docker1.1000cc.net:5000 [root@docker2 ~]# scp -p root@docker1.1000cc.net:/opt/docker/registry/certs/domain.crt /etc/docker/certs.d/docker1.1000cc.net\:5000/ca.crt domain.crt 100% 2041 1.3MB/s 00:00 [root@docker2 ~]# ls -l /etc/docker/certs.d/docker1.1000cc.net\:5000/ca.crt -rw-r--r-- 1 root root 2041 Feb 9 02:32 /etc/docker/certs.d/docker1.1000cc.net:5000/ca.crt 4) 在docker2客户端配置私有docker仓库 (1) docker版本 [root@docker2 ~]# vim /etc/sysconfig/docker OPTIONS='--insecure-registry docker1.1000cc.net:5000 --selinux-enabled --log-driver=journald.....' [root@docker2 ~]# systemctl restart docker (2) docker-ce版本 [root@docker2 ~]# vim /etc/docker/daemon.json { "registry-mirrors": ["https://3laho3y3.mirror.aliyuncs.com"], "insecure-registries": ["docker1.1000y.net:5000"] } [root@docker2 ~]# systemctl restart docker 5) 将客户端的镜像打一个标签 [root@docker2 ~]# docker tag centos docker1.1000cc.net:5000/centos:latest 6) 上传至带有SSL的私有仓库 [root@docker2 ~]# docker push docker1.1000cc.net:5000/centos:latest The push refers to a repository [docker1.1000cc.net:5000/centos] 0683de282177: Pushed latest: digest: sha256:9e0c275e0bcb495773b10a18e499985d782810e47b4fce076422acb4bc3da3dd size: 529 7) 查看仓库镜像 [root@docker2 ~]# curl -X GET https://docker1.1000cc.net:5000/v2/_catalog -k {"repositories":["centos","centos-sshd"]} 8) 在镜像仓库的主机上查看镜像信息 [root@docker1 ~]# ls /opt/registry/docker/registry/v2/repositories/centos _layers _manifests _uploads

7.3 建立基于SSL的身份验证的私有Docker仓库

1. 停掉以前的registry容器 2. 安装httpd-tools工具 [root@docker1 ~]# yum install httpd-tools -y 3. 建立认证账户与口令 [root@docker1 ~]# htpasswd -Bc /etc/docker/.htpasswd snow New password: Re-type new password: Adding password for user snow 4. 开启容器仓库 [root@docker1 ~]# docker run -itd --restart=always --name registry \ -v /opt/registry/:/var/lib/registry -v /opt/docker/registry/certs:/certs \ -v /etc/docker:/auth -p 5000:5000 \ -e REGISTRY_HTTP_TLS_CERTIFICATE=/certs/domain.crt \ -e REGISTRY_HTTP_TLS_KEY=/certs/domain.key -e REGISTRY_AUTH=htpasswd \ -e REGISTRY_AUTH_HTPASSWD_PATH=/auth/.htpasswd \ -e REGISTRY_AUTH_HTPASSWD_REALM="Registry Realm" registry 2bf60244f1408c3fbfaa244d1f18f44f79ad7bbb0450e16c8f45fbbdf6ccba60 5) 客户端登录测试 [root@docker2 ~]# docker login docker1.1000cc.net:5000 Username: snow Password: # 输入密码 Login Succeeded 6) 客户端查看仓库的镜像信息 [root@docker2 ~]# curl --user snow:123456 -XGET https://docker1.1000cc.net:5000/v2/_catalog -k {"repositories":["centos","centos-sshd"]} 7) 上传测试 (1) 给镜像打tag [root@docker2 ~]# docker tag busybox docker1.1000cc.net:5000/busybox (2) 确认客户端登录凭证 [root@docker2 ~]# cat ~/.docker/config.json { "auths": { "docker1.1000cc.net:5000": { "auth": "c25vdzoxMjM0NTY=" } } } (3) 上传镜像 [root@docker2 ~]# docker push docker1.1000cc.net:5000/busybox The push refers to a repository [docker1.1000cc.net:5000/busybox] 195be5f8be1d: Pushed latest: digest: sha256:edafc0a0fb057813850d1ba44014914ca02d671ae247107ca70c94db686e7de6 size: 527 (4) 客户端登出 [root@docker2 ~]# docker logout docker1.1000cc.net:5000 Removing login credentials for docker1.1000cc.net:5000 [root@docker2 ~]# cat ~/.docker/config.json { "auths": {} }

8.1 编写Dockerfile文件

[root@docker1 ~]# mkdir DockerFile [root@docker1 ~]# vim ./DockerFile/Dockerfile FROM centos MAINTAINER snowchuai <chuailiming@1000cc.net> ADD auto.sh /usr/sbin/auto.sh RUN dnf install -y openssh-server httpd iproute passwd && \ ssh-keygen -t rsa -q -N '' -f /etc/ssh/ssh_host_rsa_key && \ ssh-keygen -t ecdsa -q -N '' -f /etc/ssh/ssh_host_ecdsa_key && \ ssh-keygen -t ed25519 -q -N '' -f /etc/ssh/ssh_host_ed25519_key && \ sed -i 's/#IgnoreRhosts yes/IgnoreRhosts yes/g' /etc/ssh/sshd_config && \ sed -i 's/^#UseDNS yes/UseDNS no/g' /etc/ssh/sshd_config && \ sed -i 's/^GSSAPIAuthentication yes/GSSAPIAuthentication no/g' /etc/ssh/sshd_config && \ echo "123456" | passwd --stdin root && \ echo "1000cc.net" > /var/www/html/index.html && \ chmod 755 /usr/sbin/auto.sh EXPOSE 22 80 CMD /usr/sbin/auto.sh [root@docker1 ~]# vim DockerFile/auto.sh #! /bin/bash /usr/sbin/sshd -D & /usr/sbin/httpd -D FOREGROUND

8.2 生成镜像

[root@docker1 ~]# cd DockerFile [root@docker1 DockerFile]# docker build -t centos-ssh2web . Sending build context to Docker daemon 3.584 kB Step 1/6 : FROM centos ---> a1bef37e0f61 Step 2/6 : MAINTAINER snowchuai <chuailiming@1000cc.net> ---> Running in d0167a7f7c55 ---> 5917a53a734e Removing intermediate container d0167a7f7c55 Step 3/6 : ADD auto.sh /usr/sbin/auto.sh ---> e1212810223f ...... ...... Successfully built 3a153d862633 [root@docker1 DockerFile]# docker images REPOSITORY TAG IMAGE ID CREATED SIZE centos-ssh2web latest 3a153d862633 58 seconds ago 285 MB ...... ...... ...... ...... ...... ......

8.3 容器测试

[root@docker1 ~]# docker run -itd --name test -p 8080:80 -p 2222:22 centos-ssh2web c3a0f8cce342782764b6ff8a8d16fa1892af351b77bc6544d605401356d8450a [root@docker1 ~]# curl localhost:8080 1000cc.net [root@docker1 ~]# ssh root@localhost -p 2222 The authenticity of host '[localhost]:2222 ([::1]:2222)' can't be established. ECDSA key fingerprint is SHA256:Y6Wc18jnkKEP/QBgl7LtcKSfeGv2QvTIMFjD35aWwfw. ECDSA key fingerprint is MD5:2b:08:29:2e:e8:12:e5:9b:d0:27:80:54:15:c4:c2:19. Are you sure you want to continue connecting (yes/no)? yes Warning: Permanently added '[localhost]:2222' (ECDSA) to the list of known hosts. root@localhost's password: [root@c3a0f8cce342 ~]#

9.1 安装Docker Compose

# 在CentOS7中，不要下载大于1.26.2版本的compose，否则将在docker build生成新镜像时报错: unknown flag: --iidfile [root@docker1 ~]# curl -L \ "https://github.com/docker/compose/releases/download/1.26.2/docker-compose-Linux-x86_64" \ -o /usr/local/bin/docker-compose [root@docker1 ~]# chmod 755 /usr/local/bin/docker-compose [root@docker1 ~]# ln -s /usr/local/bin/docker-compose /usr/bin/docker-compose

9.2 编写Compose文件

1) 编写web及ssh的dockerfile (1) 编写web的dockerfile [root@docker1 ~]# cd DockerFile [root@docker1 DockerFile]# vim Dockerfile FROM centos MAINTAINER snow <chuai@1000cc.net> RUN yum update -y RUN yum install httpd -y EXPOSE 80 CMD ["/usr/sbin/apachectl", "-D", "FOREGROUND"] 2) 编写compose [root@docker1 DockerFile]# vim docker-compose.yml version: '3' services: db: image: mariadb volumes: - /var/lib/docker/disk01:/var/lib/mysql environment: MYSQL_ROOT_PASSWORD: password MYSQL_USER: snow MYSQL_PASSWORD: password MYSQL_DATABASE: snow_db ports: - "3306:3306" web: build: . ports: - "8080:80" volumes: - /var/lib/docker/disk02:/var/www/html 4) 目录及文件结构 [root@docker1 DockerFile]# tree . ├── docker-compose.yml ├── Dockerfile 0 directories, 2 files 3) 通过Compose生成镜像并启动容器 [root@docker1 DockerFile]# docker-compose up -d ...... ...... ...... ...... ...... ...... Creating dockerfile_db_1 ... done Creating dockerfile_web_1 ... done [root@docker1 DockerFile]# docker images REPOSITORY TAG IMAGE ID CREATED SIZE dockerfile_web latest da7b6fc0ea72 18 seconds ago 412 MB ...... ...... ...... ...... ...... ...... [root@docker1 DockerFile]# docker ps -a CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES a403c68e881d dockerfile_web "/usr/sbin/apachec..." 2 minutes ago Up 2 minutes 0.0.0.0:8080->80/tcp dockerfile_web_1 aad47e5fc73d mariadb "docker-entrypoint..." 2 minutes ago Up 2 minutes 0.0.0.0:3306->3306/tcp dockerfile_db_1

9.3 部署Harbor仓库

1) 安装好docker-ce或docekr 1.13+及docker-compose 2) 创建一个证书 [root@srv2 ~]# mkdir -p /opt/docker/registry/certs [root@srv2 ~]# openssl req -newkey rsa:4096 -nodes -sha256 \ -keyout /opt/docker/registry/certs/domain.key -x509 -days 365 \ -out /opt/docker/registry/certs/domain.crt Generating a 4096 bit RSA private key ................................................................ ................................................................ ................................................................ ................................................................ ........................................................++ .....................................................++ writing new private key to '/opt/docker/registry/certs/domain.key' ----- You are about to be asked to enter information that will be incorporated into your certificate request. What you are about to enter is what is called a Distinguished Name or a DN. There are quite a few fields but you can leave some blank For some fields there will be a default value, If you enter '.', the field will be left blank. ----- Country Name (2 letter code) [XX]:CN State or Province Name (full name) []:BeiJing Locality Name (eg, city) [Default City]:BeiJing Organization Name (eg, company) [Default Company Ltd]:1000y.cloud Organizational Unit Name (eg, section) []:tech Common Name (eg, your name or your server's hostname) []:srv2.1000y.cloud Email Address []: 3) 配置及安装harbor [root@srv2 ~]# curl -O \ https://github.com/goharbor/harbor/releases/download/v2.9.0/harbor-offline-installer-v2.9.0.tgz [root@srv2 ~]# tar xfz harbor-offline-installer-v2.9.0.tgz [root@srv2 ~]# cd harbor/ [root@srv2 harbor]# cp harbor.yml.tmpl harbor.yml [root@srv2 harbor]# vim harbor.yml ...... ...... ...... ...... ...... ...... # 修改第5行，更改HarBor主机名称 hostname: srv2.1000y.cloud ...... ...... ...... ...... ...... ...... # 修改第17-18行，更改证书所在路径及文件名 certificate: /opt/docker/registry/certs/domain.crt private_key: /opt/docker/registry/certs/domain.key ...... ...... ...... ...... ...... ...... # 注意36行,harbor_admin_password的密码 arbor_admin_password: Harbor12345 ...... ...... ...... ...... ...... ...... [root@srv2 ~]# ./prepare prepare base dir is set to /root/harbor Unable to find image 'goharbor/prepare:v2.9.0' locally Trying to pull repository docker.io/goharbor/prepare ... v2.9.0: Pulling from docker.io/goharbor/prepare ...... ...... ...... ...... ...... ...... Successfully called func: create_root_cert Generated configuration file: /compose_location/docker-compose.yml Clean up the input dir [root@srv2 ~]# ./install.sh [Step 0]: checking if docker is installed ... ...... ...... ...... ...... ...... ...... ✔ ----Harbor has been installed and started successfully.---- [root@srv2 ~]# docker-compose ps ################################################## 错误汇总 ################################################## 1. 如果重启docker服务后，可能会导致harbor有些进程无法启动，导致无法访问harbor.可按以下操作 [root@srv2 ~]# docker-compose ps [root@srv2 ~]# cd harbor/ [root@srv2 harbor]# docker-compose up -d 2. 停止所有由docker-compose启动的服务 [root@srv2 ~]# docker-compose stop ################################################## 汇总结束 ################################################## 4) 访问harbor [浏览器]---> http://harbor_srv_fqdn/ 5) 客户端准备存放证书的路径,并将crt证书复制到客户端 [root@srv1 ~]# mkdir -p /etc/docker/certs.d/srv2.1000y.cloud [root@srv1 ~]# scp -p root@srv2.1000y.cloud:/opt/docker/registry/certs/domain.crt /etc/docker/certs.d/srv2.1000y.cloud/ca.crt domain.crt 100% 2041 1.3MB/s 00:00 [root@srv1 ~]# ls -l /etc/docker/certs.d/srv2.1000y.cloud/ca.crt -rw-r--r-- 1 root root 2041 Sep 24 17:05 /etc/docker/certs.d/srv2.1000y.cloud/ca.crt 6) 在srv12客户端配置私有docker仓库 (1) docker版 [root@srv1 ~]# vim /etc/sysconfig/docker OPTIONS='--insecure-registry srv2.1000y.cloud --selinux-enabled --log-driver=journald.....' [root@docker2 ~]# systemctl restart docker (2) docker-ce版 [root@srv1 ~]# vim /etc/docker/daemon.json { "registry-mirrors": ["https://3laho3y3.mirror.aliyuncs.com"], "insecure-registries": ["srv2.1000y.cloud"] } [root@docker2 ~]# systemctl restart docker 7) 镜像上传测试 [root@srv1 ~]# docker images REPOSITORY TAG IMAGE ID CREATED SIZE docker.io/nginx latest 605c77e624dd 21 months ago 141 MB [root@srv1 ~]# docker tag docker.io/nginx:latest srv2.1000y.cloud/library/nginx [root@srv1 ~]# docker login srv2.1000y.cloud Username: admin Password: Login Succeeded [root@srv1 ~]# docker push srv2.1000y.cloud/library/nginx The push refers to a repository [srv2.1000y.cloud/library/nginx] d874fd2bc83b: Pushed 32ce5f6a5106: Pushed f1db227348d0: Pushed b8d6e692a25e: Pushed e379e8aedd4d: Pushed 2edcec3590a4: Pushed latest: digest: sha256:ee89b00528ff4f02f2405e4ee221743ebc3f8e8dd0bfd5c4c20a2fa2aaa7ede3 size: 1570 8) Chart测试 (1) 安装helm操作 [root@srv1 ~]# wget https://mirrors.huaweicloud.com/helm/v3.12.3/helm-v3.12.3-linux-amd64.tar.gz [root@srv1 ~]# tar xfz helm-v3.12.3-linux-amd64.tar.gz [root@srv1 ~]# cp linux-amd64/helm /usr/local/bin/ [root@srv1 ~]# helm version version.BuildInfo{Version:"v3.12.3", GitCommit:"...... (2) 登录仓库 [root@srv1 ~]# helm registry login srv2.1000y.cloud --insecure Username: admin Password: # 输入管理员密码 Login Succeeded (3) 准备一个已经做好的chart包 (4) push测试 [root@srv1 ~]# helm push coredns-1.26.0.tgz oci://srv2.1000y.cloud/ibrary/chart \ --insecure-skip-tls-verify Pushed: srv2.1000y.cloud/k8s/chart/coredns:1.26.0 Digest: sha256:9e824163c1530296d3b9a151f40bbba9e9d5367cb0a92d0287b1912f1b84e8ca (5) pull测试 [root@srv1 ~]# helm pull oci://srv2.1000y.cloud/ibrary/chart/coredns \ --version=1.26.0 --insecure-skip-tls-verify Pulled: srv2.1000y.cloud/k8s/chart/coredns:1.26.0 Digest: sha256:9e824163c1530296d3b9a151f40bbba9e9d5367cb0a92d0287b1912f1b84e8ca (6) logout [root@srv7 ~]# helm registry logout srv7.1000y.cloud Removing login credentials for srv7.1000y.cloud

10.1 拓扑

------------+---------------------------+---------------------------+------------ | | | eth0|192.168.10.21 eth0|192.168.10.22 eth0|192.168.10.23 +-----------+-----------+ +-----------+-----------+ +-----------+-----------+ | [ Manager Node ] | | [ Worker Node ] | | [ Worker Node ] | | [docker1.1000cc.net] | | [docker2.1000cc.net] | | [docker3.1000cc.net] | +-----------------------+ +-----------------------+ +-----------------------+

10.2 配置Swarm

1) 确认所有节点Docker版本均大于1.12 [root@docker1 ~]# docker -v Docker version 1.13.1, build 4ef4b30/1.13.1 2) 在所有节点关闭”live-restore”选项并重启docker [root@docker1 ~]# vim /etc/docker/daemon.json { "registry-mirrors":["https://3laho3y3.mirror.aliyuncs.com"], "live-restore":false } [root@docker1 ~]# systemctl restart docker 3) 在管理节点初始化Swarm [root@docker1 ~]# docker swarm init Swarm initialized: current node (59v5v5gt7f87re13107b6l69p) is now a manager. To add a worker to this swarm, run the following command: # 输出提示，将节点通过以下方式及token加入至Swarm中 docker swarm join \ --token SWMTKN-1-0n487fzobo6q8ahqgqb308743eoa676l9rsgfdsheq7w9xsn4u-48blm7ayxap6zei0okytb5et7 \ 192.168.10.21:2377 To add a manager to this swarm, run 'docker swarm join-token manager' and follow the instructions. 4) 将Worker Node加入至Swarm [root@docker2 ~]# docker swarm join \ --token SWMTKN-1-0n487fzobo6q8ahqgqb308743eoa676l9rsgfdsheq7w9xsn4u-48blm7ayxap6zei0okytb5et7 \ 192.168.10.21:2377 This node joined a swarm as a worker. [root@docker3 ~]# docker swarm join \ --token SWMTKN-1-0n487fzobo6q8ahqgqb308743eoa676l9rsgfdsheq7w9xsn4u-48blm7ayxap6zei0okytb5et7 \ 192.168.10.21:2377 This node joined a swarm as a worker. 5) 在Manager Node确认节点加入且处于Active状态 [root@docker1 ~]# docker node ls ID HOSTNAME STATUS AVAILABILITY MANAGER STATUS 59v5v5gt7f87re13107b6l69p * docker1.1000cc.net Ready Active Leader l5r2c40aswzh42cpdsdsdqp1s docker3.1000cc.net Ready Active qg02gqftuwcf9h47fpeku6rer docker2.1000cc.net Ready Active 6) 在所有节点创建一个镜像,且镜像名一致 (1) Manager Node [root@docker1 ~]# vim Dockerfile FROM centos MAINTAINER snow <chuai@1000cc.net> RUN yum -y install httpd RUN echo "docker1.1000cc.net" > /var/www/html/index.html EXPOSE 80 CMD ["-D", "FOREGROUND"] ENTRYPOINT ["/usr/sbin/httpd"] [root@docker1 ~]# docker build -t web_srv:latest . [root@docker1 ~]# docker images REPOSITORY TAG IMAGE ID CREATED SIZE web_srv latest c19913c7dd7c 54 seconds ago 283 MB ...... ...... ...... ...... ...... ...... (2) Node2 Node [root@docker2 ~]# vim Dockerfile FROM centos MAINTAINER snow <chuai@1000cc.net> RUN yum -y install httpd RUN echo "docker2.1000cc.net" > /var/www/html/index.html EXPOSE 80 CMD ["-D", "FOREGROUND"] ENTRYPOINT ["/usr/sbin/httpd"] [root@docker2 ~]# docker build -t web_srv:latest . [root@docker2 ~]# docker images REPOSITORY TAG IMAGE ID CREATED SIZE web_srv latest b064abb85035 54 seconds ago 283 MB ...... ...... ...... ...... ...... ...... (3) Node3 Node [root@docker3 ~]# vim Dockerfile FROM centos MAINTAINER snow <chuai@1000cc.net> RUN yum -y install httpd RUN echo "docker3.1000cc.net" > /var/www/html/index.html EXPOSE 80 CMD ["-D", "FOREGROUND"] ENTRYPOINT ["/usr/sbin/httpd"] [root@docker3 ~]# docker build -t web_srv:latest . [root@docker3 ~]# docker images REPOSITORY TAG IMAGE ID CREATED SIZE web_srv latest 98c0416fade6 54 seconds ago 283 MB ...... ...... ...... ...... ...... ...... 7) 启动swarm集群,设定replicas为2 [root@docker1 ~]# docker service create --name scluster --replicas=2 -p 80:80 web_srv:latest unable to pin image web_srv:latest to digest: manifest unknown: manifest unknown 8byp551bcgcox7uk6jhjtr5zs ################################################## 错误汇总 ################################################## 1. Error response from daemon: rpc error: code = 4 desc = context deadline exceeded 2. 查看 tali -f /var/log/messages | grep docker 日志，发现错误为"create serivce..." # 解决方法: 1. 编辑/etc/docker/daemon.json文件 2. 将"registry-mirrors":["https://3laho3y3.mirror.aliyuncs.com"],部分删除 3. 重启启动docker服务 4. 待成功建立service之后，在将"registry-mirrors":["https://3laho3y3.mirror.aliyuncs.com"],加入即可 ################################################## 汇总结束 ################################################## 稍等一会,REPLICAS就会准备好 [root@docker1 ~]# docker service list ID NAME MODE REPLICAS IMAGE 8byp551bcgco scluster replicated 2/2 web_srv:latest 8) 检查cluster状态 [root@docker1 ~]# docker service inspect scluster --pretty ID: 8byp551bcgcox7uk6jhjtr5zs Name: scluster Service Mode: Replicated Replicas: 2 Placement: UpdateConfig: Parallelism: 1 On failure: pause Max failure ratio: 0 ContainerSpec: Image: web_srv:latest Resources: Endpoint Mode: vip Ports: PublishedPort 80 Protocol = tcp TargetPort = 80 9) 检查服务状态 [root@docker1 ~]# docker service ps scluster ID NAME IMAGE NODE DESIRED STATE CURRENT STATE puuzn36n63mx scluster.1 web_srv:latest docker2.1000cc.net Running Running 4 minutes ago 9f034679yr4b scluster.2 web_srv:latest docker1.1000cc.net Running Running 4 minutes ago ERROR PORTS 10) 测试swarm负载均衡 [root@docker1 ~]# curl http://127.0.0.1 docker1.1000cc.net [root@docker1 ~]# curl http://127.0.0.1 docker2.1000cc.net [root@docker1 ~]# curl http://127.0.0.1 docker1.1000cc.net [root@docker1 ~]# curl http://127.0.0.1 docker2.1000cc.net 10) 增加副本节点 [root@docker1 ~]# docker service scale scluster=3 unable to pin image web_srv:latest to digest: manifest unknown: manifest unknown scluster scaled to 3 [root@docker1 ~]# docker service list ID NAME MODE REPLICAS IMAGE 8byp551bcgco scluster replicated 3/3 web_srv:latest 11) 扩展副本节点的测试 [root@docker1 ~]# curl http://127.0.0.1 docker3.1000cc.net [root@docker1 ~]# curl http://127.0.0.1 docker1.1000cc.net [root@docker1 ~]# curl http://127.0.0.1 docker2.1000cc.net [root@docker1 ~]# curl http://127.0.0.1 docker3.1000cc.net [root@docker1 ~]# curl http://127.0.0.1 docker1.1000cc.net [root@docker1 ~]# curl http://127.0.0.1 docker2.1000cc.net
